Special spacers separate the plates, isolating the channels and establishing countercurrent flow. The 1-mm (0.039-in.) thick dimpled heat exchanger plates are sandwiched between top and bottom plates specified to withstand the design pressure. Channels formed between the specially dimpled, welded plates direct the two heat transfer media countercurrently through alternate paths for maximum efficiency, immediate thermal response and a close temperature approach capability of less than 1☌ (2☏). The unique geometry of the patented MAXCHANGER’s variable interspaces produce extremely high “U” values. MAXCHANGER single- and multiple-pass designs fit virtually any application requirement. MaxChanger – The Design Engineer’s Friend The SUPERMAX can be installed horizontally or vertically horizontal installation is recommended for condensing/evaporating/boiling applications. The SUPERMA X is particularly suited to applications having a large flow imbalance, allowing higher flow rates on the shell side. SUPERMAX wide temperature/pressure ratings offer good performance with natural refrigerants such as ammonia and carbon dioxide.Fluids can undergo phase change on either the plate or shell side. They are also resistant to freezing because of high fluid turbulence induced by the corrugated plate pattern. In refrigeration and cryogenic service, the exchangers require a low refrigerant charge. Extended range units are available for higher temperature and pressure applications.Turbulent flow, even at low velocities, enables stable capacity regulation and minimizes fouling. The SUPERMAX® Shell & Plate Heat Exchanger is designed for pressures to 200 barg (2900 psig) and at temperatures up to 900☌ (1650☏) for standard range units. Supermax for amazing efficiency in a small footprint
Tranter maxchanger manual#
See the Platecoil® Data Manual for configurations, sizes and materials.TRANTER Shell & Plate Welded Heat Exchanger Type 316L SS PLATECOIL® units are available in 14 and 16 gauge (1.9 mm and 1.5 mm) material. Carbon steel PLATECOIL® are available in 12 and 14 gauge (2.7 mm and 1.9 mm) material. In addition to carbon steel and stainless steel, PLATECOIL® can be fabricated from such materials as Monel, nickel and a variety of other corrosion resistant materials.
Tranter maxchanger series#
Other 300 series stainless steels are available. carbon and 0.25 to 0.50% manganese) and Type 316L SS. Materials Standard PLATECOIL® materials include Type SA-414 SS (0.15% max. Large pass, heavy gauge PLATECOIL® is another option available to satisfy requirements for high internal flow rates, low pressure drops and rugged use.
Several types of surface finishes can be provided to minimize fouling and reduce maintenance. Construction PLATECOIL® can be bent, rolled, or otherwise formed into virtually any configuration. Orders can often be shipped within a matter of a few days. A large inventory of standard PLATECOIL® is maintained. Each unit is hydrostatically pressure tested before shipping to assure structural integrity. PLATECOIL® is manufactured in compliance with strict quality control standards. Length dimensions range from 584 mm to 3, 632 mm (23 in. Standard PLATECOIL® panels are available in more than 300 sizes widths range from 305 mm to 1, 092 mm (12 in. When welded together, the embossings form a series of well-defined passages through which the heat transfer media flows. PLATECOIL® Prime Surface Heat Exchangers are fabricated from two metal sheets, one or both of which are embossed. Flexibility for a wide variety of applications - High-efficiency plate pattern designs and flow configurations - Unique, neutral-plane gasket groove design and the ability to configure PHE units in a parallel or diagonal flow configuration - Ease if assembly or disassembly for inspection, maintenance and capacity expansion View Complete Details The unit also offers “U” or “K “values 3 to 6 times higher than shell & tube exchangers. Features - Outstanding efficiency in transferring heat from one liquid to another OR from steam to liquid - Compact footprint – using just 20–50% of a shell & tube Heat Exchangers - Offers variety of configurations through Modular exchange system combining frames, plates and connections - Approaches of less than 1☌ (2☏). We have begun manufacturing and designing maintenance-friendly value added solutions with an intension to maximize our customer’s process outputs and also their return on investment in our PHE’s. We have gone beyond simply designing Plate Heat Exchangers that meet the specs highlighted by customers. Our Heat Exchangers have been designed based on the feedback from customers. Tranter is entering its fifth decade of engineering and manufacturing Gasketed Plate Heat Exchangers.
